Technical Specifications
| Testing machine for blower | |
| Item | Machine Specification |
| Machine name? | Testing machine for blower |
| Model no. | T-E |
| Main components specification | Motor: Oriental motor |
| Sensor : KEYENCE, OMRON, CONTROLWAY | |
| Vibration sensor: ZHONGHANG, JIZHI Balancing Machines (JZABM) | |
| Touch screen : KEYENCE 10.4′,PROFACE | |
| Control PLC: KEYENCE | |
| Data collection: KEYENCE | |
| Cylinder: SMC | |
| Rotation control: DC motor controller | |
| Rotor apply range | Car blower? |
| Speed | 1500-2100rpm |
| Positioning method | External motor assist positioning |
| Power supply | AC220V |
| Air supply | 0.4~0.6Mpa |
| Cycle time | ≤10s? |
| Repetitiveness | ±3mg |
| Volume | 900x 650 x1350mm |
Product Features
01
High application range;
02
Test time 8-10 Sec;
03
Auto-positioning, laser & lamp indicate the clip weight/quantity and add point；
04
Easy operation. For operator, it just spends short time on training；
Application
The machine is the balance testing equipment.
This machine is mechatronics equipment，whic use PLC as the main control machine，complete the relevant calculation and motion control.Use the touch screen as man-machine interface，Set parameters and operate the machine.
