Brake Disc Dynamic Balancing Machine

Name: Brake Disc Dynamic Balancing Machine
Brand: JIZHI Balancing Machines (JZABM)

Jizhi's fully automatic balancing machine is suitable for disc-type components with center holes or shafts, such as brake discs, brake rotors, brake drums, impellers, and other similar parts. Jizhi's fully automatic brake disc balancing machine features high precision and high efficiency, with a cycle time (initial measurement + milling + re-measurement) during which testing and milling are carried out simultaneously.

Request configuration

Technical Specifications

Balancing Speed	500–900 rpm
Cutting Method	T-type cutter outer diameter milling
Residual Unbalance Eccentricity	Better than G6.3 of national standard (GB/T 9239)
Working Cycle Time	30–40 s
Workpiece Inner Hole Diameter	Φ54–91 mm (customizable)
Workpiece Outer Diameter	Φ220–410 mm
Milling Width	10–30 mm
Milling Depth	≤5 mm

Product Features

1. High precision and high efficiency: The equipment achieves a cycle time (initial measurement + milling + re-measurement) of 40 seconds, with testing and milling carried out simultaneously.

2. Single-plane balancing, cylindrical or end-face milling, rapid changeover, parameterized adjustment, simple operation, and strong compatibility.

3. Capable of standalone automatic balancing, integration into fully automatic production lines, and supporting MES system connectivity for data traceability.
