Technical Specifications
| Type | RDB-100A | RDB-100B | RDB-250B | RDB-100D |
|---|---|---|---|---|
| Specification | ||||
| Mass Range of Rotor (kg) | 5-100 | 5-100 | 5-250 | 20-100 |
| Max. Diameter (mm) | φ130 | φ130 | φ150 | φ130 |
| Machine Bed Length (mm) | 4430 | 4430 | 5030 | 5030 |
| Balance Speed (r/min) | 1600-4000 | 1600-4000 | 1200-3200 | 1200-3200 |
| Motor Power (kW) | 3 | 3 | 7.5 | 3 |
| Max. Initial Unbalance (g·cm) | 500 | 500 | 1000 | 500 |
| Min. Sensitivity (g·cm) | 5 | 5 | 5 | 5 |
Product Features
1. For this series of equipment, before starting, simply adjust according to the radii of the two correction planes of the rotor, and the unbalance amount and phase of the workpiece will be correctly displayed after a single start-up.
2. The new-generation dedicated electrical measurement system HW310, which works with this machine, is based on a PLC platform. It features stable measurement, comprehensive functionality, touch screen operation, and powerful human-machine interaction capabilities.
3. This series of equipment can be optionally equipped with a projection welding machine to facilitate the welding of balance weights to the shaft tube during dynamic balancing of the driveshaft, thereby reducing the operator’s workload and improving production efficiency.
Technical overview
- Model
- RDB-100D
